Our Infrastructure
MAX. Turning Dia & length 850 mm 12 Station Turret 22/18.5 kW Spindle Power Speed Range 1000 rpm FANUC Oi TF
CNC VTL - Model BVL 800H
MAX. Turning Dia & length 700 mm 12 Station Turret 22/18.5 kW Spindle Power Speed Range 1000 rpm FANUC Oi TF
CNC VTL - Model BVL 700H
X Axis – 1050, Y Axis – 610, Z Axis – 610, 4 Axis – 250 Dia, UCam Rotary Table, 7.5/11 kW Spindle Power, 250 mm dia Ucam Rotary ATC 24 , Speed Range 6000 rpm , FANUC Oi TF.
VMC - Model BMV60+TC24 -2 Nos
X Axis – 1250, Y Axis – 625, Z Axis – 600 + 300 = 900, 4 Axis – 320 Dia, UCam Rotary Table, 15/18 kW Spindle Power, ATC 30, Speed Range 8000 rpm , FANUC Oi TF,
VMC - Model DM6700TC30
MAX. Turning length 1000 mm Max. Turning Dia. 480 mm 8 Station Turret Chuck Dia 254 mm FANUC
CNC Turning - Model DX250
MAX. Turning length 500 mm, Max. Turning Dia. 320 mm, 8 Station Turret , Chuck Dia 250 mm, FANUC .
CNC Turning-1 - Model LL20T L5
MAX. Turning length 700 mm, Max. Turning Dia. 320 mm, 8 Station Turret , Chuck Dia 250 mm, FANUC .
CNC Turning-2 - Model LL25T L7
X Axis – 560, Y Axis – 560, Z Axis – 560, 4 Axis – 0.5 Degree, Table: 400x400 double . pallet , ATC 40 , 15/18 kW Spindle Power, Speed Range 8000 rpm
HMC - Model H40TC40
Stroke 100 mm, Max. Dia. 400, MIN. Dia. 50, 11 kW Spindle Power.
CNC GEAR SHAPPER - Model 400S
Model OHA 50A , Stroke 125 mm, Max. Dia. 500 , MIN. Dia. 200, 15 kW Spindle Power ..
SEMI CNC GEAR SHAPPER - Model OHA 50A
Stroke 80 mm, Max. Dia. 600, MIN. Dia. 50, 10 kW Spindle Power.
MANNUAL GEAR SHAPPER - Model OH6
Code 1604161, MAX DRILLING DIAMETER, . 50 mm , ARM LENGTH 1600 mm, , SPINDLE 2000 rpm, CUBE SIZE 750 x 550 x 500 mm .
DRILLING MACHINING - Model F50/1600
Max. Dia. 600 mm RPM – 450 1” Drilling Machine With Computer
Balancing Machine - Model BM450
Max. Stroke. 1500 mm Capacity – 10Ton Motor – 20 HP
Broaching Machine - LAPOINTE H20
X Axis – 2100 MM, Y Axis – 1500 MM, Z Axis – 1500 MM
DOOSAN HMC
Make : BFW HMC Model : BFW HMC Size : X :900mm Y :750mm Z :630mm.
BFW HMC
MAX. Turning Dia & length 850 mm, 12 Station Turret 22/18.5 kW Spindle Power Speed Range 1000 rpm FANUC Oi TF
CNC VTL - Model BVL 800H
Max Pulling Force - 25 TONS, Feeder Stroke for Change of Component mm 630,Follow on Stroke of feeder mm. 1400, Cutting Speed (Infinitely Variable) M / Min 7.5, Return Stroke Speed M / Min 24, With of face plates mm. 500
25 TON VERTICAL BROACHING MACHINE
Make : Hexagon Metrology Model : CROMA (Fully Automated & Gear Profile) Size : X :800mm Y :1000mm Z :600mm Accuracy : 0.10µm Max. Load : 500kg .
Coordinate Measuring Machine - CROMA (Fully Automated & Gear Profile)
Surface Plate : Granite Surface Table Size 1600X1000X200mm, 2D Height Gauge : 700 mm, Trimos V7 Roughness Tester : Mitutoyo SJ-210 Bore Dial : up to 500 mm range, Depth Vernier : 0-300 mm, Micrometers : up to 500 mm range, Digital Vernier : up to 300mm, Vernier : up to 600mm. Inside Micrometer : 50 – 1000mm And Inside & Outside Calipers
Coordinate Measuring Machine
MODEL: OPAB-3000N MAKE : FSA MEASURING RANGE 131 BHN TO 1464 BHN BALL DIA 5 MM LOAD IN KG 750 TO 62.50 KG BALL DIA 10 MM LOAD IN KG 3000 TO 250 KG
OPTICAL BRINELL HARDNESS TESTING MACHINE - MODEL: OPAB-3000N
ANALOG AIR GAUGE UNIT
DIGITAL AIR GAUGE UNIT
MASTE AIR PLUG &RINGGAUGE
BEAMGAUGE
SNAPGAUGE
MASTER AIR RING & OD PLUG GAUGE
